Hikvision Gen2 7" IP Touch Screen Indoor WIFI Monitor (DS-KH6320-WTE1)

Product Description

Specifications

Model Number: DS-KH6320-WTE1

System

Memory	128 MB
Flash	32 MB
Operating System	Embedded Linux

Display

Size	7" / 17.8 cm
Resolution	1024 x 600
Type	TFT LCD Capacitive Touchscreen

Audio

Input	Built-In Omnidirectional Microphone
Output	Built-In Loudspeaker
Compression	G.711 U
Compression Rate	64 kb/s
Audio Quality	Noise Suppression and Echo Cancellation

Network

Wired Network	100M Self-Adaptive Network
Wireless Network	802.11b/g/n
Protocols	TCP/IP, SIP, RTSP
Interface	100M Self-Adaptive RJ45 Port
Alarm Inputs	8
Relay Outputs	2
RS-485	1 x RS-485
Memory Card	Supports microSD Cards up to 32 GB (SD 2.0 or Lower)

General

Power	802.3af, Standard PoE 12 VDC, 1 A
Power Consumption	≤6 W
Operating Temperature	14 to 131°F / -10 to 55°C
Operating Humidity	10 to 90%, Non-Condensing
Frame	Display Frame: Plastic
Dimensions (W x H x D)	7.9 x 5.5 x 0.6" / 200 x 140 x 15.1 mm

Packaging Info

Package Weight	1.385 lb
Box Dimensions (LxWxH)	10.2 x 7.3 x 2.2"
